Cold-formed equilateral channel steel
Cold-formed equilateral channel steel
Channel steel, also known as C-Channel or Parallel Flange Channel (PFC), is a type of profile, which belongs to carbon structural steel for construction and machinery, and is a section steel with complex sections. Channel steel is mainly used in building structure, curtain wall engineering, mechanical equipment and vehicle manufacturing.
[email protected]
Email:
+8613396350973
Whatsapp:
PRODUCT DESCRIPTION
Channel steel, also known as C-Channel or Parallel Flange Channel (PFC), is a type of profile, which belongs to carbon structural steel for construction and machinery, and is a section steel with complex sections. Channel steel is mainly used in building structure, curtain wall engineering, mechanical equipment and vehicle manufacturing.
Classification of channel steel
Channel steel is divided into ordinary channel steel and light channel steel. The specification of hot-rolled ordinary channel steel is 5-40#. The specification of hot-rolled flexible channel steel supplied by agreement between the supplier and the buyer is 6.5-30#. Channel steel is mainly used in building structures, vehicle manufacturing, other industrial structures and fixed cabinets, etc. Channel steel is often used in conjunction with I-beam steel.
Channel steel can be divided into 4 types according to shape: cold-formed equilateral channel steel, cold-formed unequal-sided channel steel, cold-formed inner-curled channel steel, and cold-formed outer-curved channel steel.
According to the theory of steel structure, the channel steel wing plate should be stressed, that is to say, the channel steel should be standing, not lying down.
Specification and theoretical weight of channel steel (unit: kg/m, mm)
| Specification | High | Leg Width | Waist Thick | Sectional Area(cm²) | Theoretical Weight | ||||
| 5# | 50 | 37 | 4.5 | 6.928 | 5.438 | ||||
| 6.3# | 63 | 40 | 4.8 | 8.451 | 6.634 | ||||
| 6.5# | 65 | 40 | 4.3 | 6.709 | |||||
| 8# | 80 | 43 | 5.0 | 10.248 | 8.045 | ||||
| 10# | 100 | 48 | 5.3 | 12.748 | 10.007 | ||||
| 12# | 120 | 53 | 5.5 | 12.059 | |||||
| 12.6 | 126 | 53 | 5.5 | 15.692 | 12.319 | ||||
| 14#a | 140 | 58 | 6.0 | 18.516 | 14.535 | ||||
| 14#b | 140 | 60 | 8 | 21.316 | 16.733 | ||||
| 16#a | 160 | 63 | 6.5 | 21.962 | 17.24 | ||||
| 16#b | 160 | 65 | 8.5 | 25.162 | 19.752 | ||||
| 18#a | 180 | 68 | 7 | 25.699 | 20.174 | ||||
| 18#b | 180 | 70 | 9 | 29.299 | 23 | ||||
| 20#a | 200 | 73 | 7 | 28.837 | 22.637 | ||||
| 20#b | 200 | 75 | 9 | 32.837 | 25.777 | ||||
| 22#a | 220 | 77 | 7 | 31.846 | 24.999 | ||||
| 22#b | 220 | 79 | 9 | 36.246 | 28.453 | ||||
| 25#a | 250 | 78 | 7 | 34.917 | 27.41 | ||||
| 25#b | 250 | 80 | 9 | 39.917 | 31.335 | ||||
| 25#c | 250 | 82 | 11 | 44.917 | 35.26 | ||||
| 28#a | 280 | 82 | 7.5 | 40.034 | 31.427 | ||||
| 28#b | 280 | 84 | 9.5 | 45.634 | 35.832 | ||||
| 28#c | 280 | 86 | 11.5 | 51.234 | 40.219 | ||||
| 30#a | 300 | 85 | 7.5 | 34.463 | |||||
| 30#b | 300 | 87 | 9.5 | 39.173 | |||||
| 30#c | 300 | 89 | 11.5 | 43.883 | |||||
| 32#a | 320 | 88 | 8 | 48.513 | 38.083 | ||||
| 32#b | 320 | 90 | 10 | 54.913 | 43.107 | ||||
| 32#c | 320 | 92 | 12 | 61.313 | 48.131 | ||||
| 36#a | 360 | 96 | 9 | 60.910 | 47.814 | ||||
| 36#b | 360 | 98 | 11 | 68.110 | 53.466 | ||||
| 36#c | 360 | 100 | 13 | 75.310 | 59.118 | ||||
| 40#a | 400 | 100 | 10.5 | 75.068 | 58.928 | ||||
| 40#b | 400 | 102 | 12.5 | 83.068 | 65.208 | ||||
| 40#c | 400 | 104 | 14.5 | 91.068 | 71.488 | ||||
Packing and shipping
The company has domestic first-class professional technical consultants and a team of outstanding employees with professional skills. The main products are carbon steel/galvanized steel. Stainless steel/steel coil steel bars, galvalume, color-coated coils, profiles, steel bars, aluminum products, roof panels. Products are sold to more than 60 countries and regions in Europe, the Middle East, Southeast Asia, and Australia.
FACTORY APPEARANCE
Company As 20000 Square Meters Of Indoor Storage more Than 20,000 Tons Of Inventory, Spot Product Standard Involves European Standard American Standard British Standard Australian Standard German Standard, Now According To Customer Requirements For Product Opening Strip.Cutting.Processing.Annual sales of more than 60 milliontons.Our company owns the firs class professional technique adviser in China and the excellent staffs with professional technology.The main products are carbon steel / galvanized.
PRODUCT DESCRIPTION
We promise”complete specifications, prompt delivery, high quality, competitive price, “The unwavering supports you provide, along with the increasing requirements you put contributes to more varied high-quality products with more competitive prices we offer.Win-win situations are always our pursuit.
OUR ADVANTAGE
We have won recognition from our clients due to our good creditand good services.
